Number |
Title |
Description |
Price $ |
|
1. |
Cover (gusyatnitsy) |
||
|
2. |
Gland |
Size 15/30/7 mm. |
|
|
3. |
Spring |
||
|
4. |
Breather pipe |
||
|
5. |
The gland |
||
|
6. |
Front cover crankcase |
||
|
7. |
Hairpin crankcase |
||
|
8. |
Gasket |
||
|
9. |
Hairpin crankcase |
M5 * 1 |
|
|
10. |
Hairpin crankcase cover |
||
|
11. |
Housing cover with the front bearing tube |
||
|
12. |
Ball-bearing |
Size 72/35/17 mm. |
|
|
13. |
Bearing housing front |
||
|
14. |
The sliding sleeve |
||
|
15. |
Crankcase |
||
|
16. |
Clamp generator |
||
|
17. |
Gasket Generator |
||
|
18. |
Valve cover hatch |
||
|
19. |
Gasket |
||
|
20. |
Stopper with a feeler |
||
|
21. |
Emphasis generator |
||
|
22. |
Hairpin crankcase |
||
|
23. |
Filler plug with dipstick |
||
|
24. |
Hairpin crankcase |
Short M8 * 1 |
|
|
25. |
Hairpin crankcase |
Long M10 * 1.5 |
|
|
26. |
Pallet |
||
|
27. |
Sealing washer |
||
|
28. |
Drain plug |
||
|
29. |
Pallet lining |
||
|
30. |
Gasket |
||
|
31. |
Rear housing |
||
|
32. |
Locking crunches |
|
Number |
Title |
Description |
Price $ |
|
39. |
Crankshaft assembly |
||
|
40. |
Washer keyhole |
||
|
41. |
Washer |
||
|
42. |
Motor pinion |
||
|
43. |
Oil catch |
||
|
44. |
Cheek crankshaft front |
||
|
45. |
Spline gear |
||
|
46. |
Bushing upper crosshead |
||
|
47. |
Split Ring |
||
|
48. |
Piston pin |
||
|
49. |
Piston |
||
|
50. |
Piston ring compression |
||
|
51. |
Connecting rod |
||
|
52. |
Cheek crankshaft average |
||
|
53. |
Cheek crankshaft rear |
||
|
54. |
Flywheel key |
||
|
55. |
Spring washer |
||
|
56. |
Gasket |
||
|
57. |
Flywheel |
||
|
58. |
Finger grip |
||
|
59. |
Washer |
||
|
60. |
Flywheel bolts |
|
Number |
Title |
Description |
Price $ |
|
61. |
Cylinder head right |
||
|
62. |
Head gasket |
||
|
63. |
Right Cylinder |
||
|
64. |
Stud for mounting the carburetor |
M8 * 1.5 |
|
|
65. |
Gasket carburetor |
||
|
66. |
Gasket |
||
|
67. |
Cylinder Left |
||
|
68. |
Cylinder Left |
||
|
69. |
Gasket Bolt |
||
|
70. |
Head bolts |
|
Number |
Title |
Description |
Price $ |
|
79. |
Rotor breather |
||
|
80. |
Pinion timing cam roller |
||
|
81. |
Motor pinion |
||
|
82. |
Spline gear |
||
|
83. |
Flange camshaft |
||
|
84. |
Spline |
||
|
85. |
Camshaft gear lubricating pump |
||
|
86. |
Camshaft gear lubricating pump |
||
|
87. |
Pusher |
||
|
88. |
Pushrod guide |
||
|
89. |
Bolt pusher |
M8 * 1 |
|
|
90. |
Bracket |
||
|
91. |
Locking crunches |
||
|
92. |
Spring Cap |
||
|
93. |
Spring |
||
|
94. |
Spring Cap |
||
|
95. |
Seals |
||
|
96. |
Valve |
||
|
97. |
Bearing |
Dimensions 52/25/15 mm. |
|
Number |
Title |
Description |
Price $ |
|
110. |
Oil pump drive gear |
||
|
111. |
The drive shaft of the oil pump |
||
|
112. |
Gasket |
||
|
113. |
The cover of the oil pump |
||
|
114. |
Mesh oil filter |
