Number |
Title |
Description |
|
265. |
Transaxle |
|
|
266. |
Brake Pads 2Pcs. |
|
|
267. |
Fungi 2pcs. |
|
|
268. |
Adjusting Bolt |
|
|
269. |
Spring 2pcs. |
|
|
270. |
Screw |
|
|
271. |
Brake Lever |
|
Number |
Title |
Description |
|
275. |
Aluminum ring |
|
|
276. |
Gland |
|
|
277. |
Bolt + Washer |
M6 |
|
278. |
||
|
279. |
Crankcase |
|
|
280. |
Drain plug |
|
|
281. |
Gasket Aluminum |
|
|
282. |
Bush |
|
|
283. |
Gasket |
|
|
284. |
Cover the crankcase |
|
|
285. |
Washer + nut |
M8x1 |
|
285a. |
Screw |
M10x1 - 10x1,5 |
|
286. |
Screw under the shock absorber |
|
|
287. |
Hairpin crankcase |
M8x1,5-8x1 |
|
288. |
Spline |
|
|
289. |
Gasket |
|
|
290. |
Oil dipstick |
|
|
291. |
Cork Oil dipstick |
|
|
292. |
Bush |
|
|
293. |
Spring omentum |
|
|
294. |
Screw |
M6 |
|
Number |
Title |
Description |
|
300. |
Lining |
|
|
301. |
Cogwheel |
|
|
302. |
Keyhole washer |
|
|
303. |
||
|
304. |
Bolt |
M8x1,5 |
|
305. |
Ball-bearing |
72x35 * 17 |
|
306. |
Gasket |
|
|
307. |
Bush |
|
|
308. |
Felt pad |
|
|
309. |
Spline |
3x15,8 |
|
310. |
Twisted gland 2 pcs. |
49,3x33,8x8 |
|
311. |
Spring gland 2pcs. |
|
|
312. |
Nut |
|
|
313. |
O-Ring |
|
|
314. |
Adjusting nut |
|
|
315. |
Ball-bearing |
52x20 * 22,22 |
|
316. |
Cogwheel |
32x13 * 20 |
|
317. |
Bearing |
|
Number |
Title |
Description |
|
320. |
Housing diffirentsiala |
|
|
321. |
Aluminum gasket + oil drain plug |
|
|
322. |
Gasket |
|
|
323. |
Cover the crankcase |
|
|
324. |
Nut + washer |
M8x1 |
|
325. |
Hairpin 2 pcs. |
M8x1,5 - M8x1 |
|
326. |
Gasket |
|
|
327. |
Spline |
|
|
328. |
Bush |
|
|
329. |
Aluminum gasket + oil drain plug |
|
|
330. |
||
|
331. |
Spring omentum |
|
|
332. |
Screw |
M6 |
|
333. |
Gland |
|
|
334. |
Aluminum Cover |
|
|
335. |
Nut + washer |
M6 |
|
335a. |
||
|
336. |
Nut |
|
|
337. |
The main body of the differential |
|
|
338. |
Gasket |
|
|
339. |
Oil dipstick |
|
|
340. |
Cover Oil dipstick |
|
|
341. |
Screw |
M5 |
|
342. |
Oil filler cap |
|
|
343. |
Gasket |
|
Number |
Title |
Description |
|
350. |
Rubber cover |
|
|
351. |
The rubber cover cap gear |
|
|
352. |
Bell reducer |
|
|
353. |
The propeller shaft gear |
|
|
354. |
Spline |
|
|
355. |
Bracket |
|
|
356. |
Screw + washer + gasket |
|
|
357. |
Spline |
|
|
358. |
Nut, lining 8mm |
M8x1 |
|
359. |
Gland |
49x34 * 8 |
|
360. |
Spring omentum |
|
|
361. |
Nut reducer |
|
|
362. |
O-Ring |
|
|
363. |
Lining |
|
|
364. |
Bearing |
52x20 * 22,22 |
|
365. |
Bush |
|
|
366. |
Bearing |
47x20 * 14 |
|
367. |
The pinion gear |
|
|
368. |
Wedge Araneus cardan |
|
|
369. |
Plugs Araneus cardan |
|
|
370. |
||
|
371. |
Axle nut strollers |
|
|
372. |
Lining |
|
|
373. |
The axis of the wheel strollers |
|
|
374. |
Ball-bearing |
62x30 * 15 |
|
375. |
Spring omentum |
|
|
376. |
Gland |
38x24,8 * 8 |
|
377. |
Bush |
|
|
378. |
||
|
379. |
Bearing |
80x50 * 16 |
|
380. |
Lining flat |
|
|
381. |
||
|
382. |
Nut |
|
Number |
Title |
Description |
|
420. |
Gear cover perednyayaya |
|
|
421. |
Gasket |
|
|
422. |
Bush |
|
|
423. |
Bolt |
59,6x51x5 |
|
424. |
Washer + oil drain plug |
|
|
425. |
8mm |
|
|
426. |
Gear cover back |
|
|
427. |
Spring omentum |
|
|
428. |
Gland |
59,6x51x5 |
|
429. |
The gland aluminum |
|
|
430. |
Screw |
|
|
431. |
Gear housing |
|
|
432. |
Lining sealing |
|
|
433. |
Oil dipstick gearbox |
|
|
434. |
Cover Oil dipstick |
